1993 Super 50 in 1 Game

-- create the module's table
local dumpmg109 = {}

-- import required modules
local dict = require "scripts.app.dict"
local nes = require "scripts.app.nes"
local dump = require "scripts.app.dump"
local flash = require "scripts.app.flash"
local time = require "scripts.app.time"
local files = require "scripts.app.files"
local swim = require "scripts.app.swim"
local buffers = require "scripts.app.buffers"

-- local functions
local function create_header( file, prgKB, chrKB )
    -- Mapper : 200 ; Mirroring : 0 (Horizontal)

    nes.write_header( file, prgKB, chrKB, 200, 0)
end

--dump the PRG ROM
local function dump_prgrom( file, rom_size_KB, debug )

    --PRG-ROM dump 16KB at a time
    local KB_per_read = 16
    local num_reads = rom_size_KB / KB_per_read
    local read_count = 0
    local addr_base = 0x80  -- $8000

print("CPU dump :")

    while ( read_count < num_reads )
    do
        if debug then print( "dump PRG part ", read_count, " of ", num_reads) end

        -- pause of 1 second to take care about the chips
        local time=os.clock()+1
        while time>os.clock()
            do
            end

        local nobusconflicts = dict.nes("NES_CPU_RD", 0x8000 | read_count);
        dict.nes("NES_CPU_WR", 0x8000 | read_count , nobusconflicts)

        dump.dumptofile( file, KB_per_read, addr_base, "NESCPU_PAGE", false )

        read_count = read_count + 1
    end
end

--dump the CHR ROM
local function dump_chrrom( file, rom_size_KB, debug )

    local KB_per_read = 8   --dump both PT at once
    local num_reads = rom_size_KB / KB_per_read
    local read_count = 0
    local addr_base = 0x00  -- $0000


print("PPU dump :")

    while ( read_count < num_reads ) do

        if debug then print( "dump CHR part ", read_count, " of ", num_reads) end

        -- pause of 1 second to take care about the chips
        local time=os.clock()+1
        while time>os.clock()
            do
            end

        local nobusconflicts = dict.nes("NES_CPU_RD", 0x8000 | read_count);
        dict.nes("NES_CPU_WR", 0x8000 | read_count , nobusconflicts)

        dump.dumptofile( file, KB_per_read, addr_base, "NESPPU_PAGE", false )

        read_count = read_count + 1
    end
end

--Cart should be in reset state upon calling this function
--this function processes all user requests for this specific board/mapper
--local function process( test, read, erase, program, verify, dumpfile, flashfile, verifyfile)
local function process(process_opts, console_opts)
    local test = process_opts["test"]
    local read = process_opts["read"]
    local erase = process_opts["erase"]
    local program = process_opts["program"]
    local verify = process_opts["verify"]
    local dumpfile = process_opts["dump_filename"]
    local flashfile = process_opts["flash_filename"]
    local verifyfile = process_opts["verify_filename"]

    local rv = nil
    local file
    local prg_size = console_opts["prg_rom_size_kb"]
    local chr_size = console_opts["chr_rom_size_kb"]
    local wram_size = console_opts["wram_size_kb"]

--initialize device i/o for NES
    dict.io("IO_RESET")
    dict.io("NES_INIT")

print("\nRunning dumpMG109.lua")

--dump the cart to dumpfile
    if read then
        print("\nDumping ROM...")

        file = assert(io.open(dumpfile, "wb"))

        --create header: pass open & empty file & rom sizes
        create_header(file, prg_size, chr_size)

        --TODO find bank table to avoid bus conflicts!
        --dump cart into file
        time.start()
        --dump cart into file
        dump_prgrom(file, prg_size, false)
        dump_chrrom(file, chr_size, false)
        time.report(prg_size)

        --close file
        assert(file:close())
        print("DONE Dumping ROM")
    end

    dict.io("IO_RESET")
end

-- functions other modules are able to call
dumpmg109.process = process

-- return the module's table
return dumpmg109
